Electro Plating, High-Purity Solvents

Hydropropyl Ethylene Diamine

N,N,N’,N’-Tetrakis(2-hydroxypropyl)ethylenediamine, identified by CAS number 102-60-3 and often marketed under the trade name Quadrol, is a versatile amino alcohol used extensively across several industrial sectors. This viscous, colorless to pale yellow liquid is a tertiary amine functionalized with four hydroxyl groups, providing it with unique cross-linking and neutralizing capabilities. Chemically, it acts as a high-performance polyol, frequently employed in the production of rigid polyurethane foams and elastomers where it enhances structural integrity. Its alkanolamine nature allows it to serve as an effective chelating agent for metal ions, particularly in electroless copper plating processes. Beyond industrial manufacturing, its exceptional stability and mildness make it a staple ingredient in the personal care industry, where it functions as a pH adjuster and stabilizer in various cosmetic formulations. Its multifunctional molecular architecture ensures it remains a critical component in advanced chemical synthesis, polymer science, and specialty coating applications globally, balancing reactivity with physical performance.

Attributes

Key Features and Benefits

High cross-linking density due to quad-functional hydroxyl groups.
Provides exceptional thermal stability and chemical resistance in polymers.
Functions as a powerful chelating agent for multi-valent metal cations.
Acts as an efficient pH buffer and neutralizing agent in aqueous systems.
Low volatility ensures minimal atmospheric emissions during industrial processing.
Enhances mechanical strength and rigidity in polyurethane foam systems.
Promotes superior adhesion in specialized coating and adhesive formulations.
Non-corrosive nature towards most industrial equipment and sensitive substrates.
Improves the clarity and shelf-life of complex cosmetic and dermatological preparations for consumer use.

Specifications

Technical Highlights

Molecular weight: 292.42 g/mol.
Boiling point: approximately 190°C at 1 mmHg.
Viscosity: high, typically around 35,000 to 60,000 cps at room temperature.
Hydroxyl value: approximately 750 to 800 mg KOH/g.
Amine value: typically 375 to 390 mg KOH/g.
Solubility: completely miscible with water, ethanol, and most organic solvents.
Chemical structure: four 2-hydroxypropyl groups bonded to an ethylenediamine backbone.
Vapor pressure: extremely low at ambient conditions.
Refractive index: 1.48 at 20°C.
Specific gravity: 1.03 at 25°C.
Flash point: exceeds 150°C, ensuring high safety during heated processing.

Download Technical Data Sheet (TDS)

Practical industry uses

Applications

Primary cross-linker for rigid polyurethane foams and semi-rigid elastomers.
Essential complexing agent in electroless copper and nickel plating baths.
Effective pH adjuster and viscosity modifier for skin lotions and creams.
Crucial additive in the synthesis of epoxy resins and curing agents.
Metalworking fluid component providing corrosion inhibition and lubricant stability.
Dispersant for pigments in waterborne paints and industrial coating systems.
Building block for manufacturing specialized surfactants and textile auxiliaries.
Component in gas treatment processes for removal of acidic impurities.
Catalyst promoter in specific polymerization reactions requiring controlled reactivity.
